PVC Offset Waste & Overflow Testable Rough-In Half Kit with Condensate Hub (5125TDRI-HK)

The OS&B 5125TDRI-HK is a testable 1-1/2" Schedule 40 PVC bath drain half kit, an offset waste and overflow with a 3/4" condensate connection. As a testable half kit it comes less tee, less pipe and less trim, with test devices. The test plug is rated at 25 PSI, to test up to four floors.

Features

• Condensate opening with 3/4" solvent connection
• Spin-on tie plate for a toolless installation
• Angle adapter included; use is optional
• Thick foam overflow gasket with adhesive back
• Overflow head with an integrated 6 degree angle
• Overflow head with aggressive threads for a quicker and easier installation
• Self-clinging rubber waste gasket
• Coarse thread strainer
• Thread-in waste test plug with stainless steel post

Specifications

• Size: 1-1/2"
• Material: Schedule 40 PVC
• Condensate connection: 3/4" solvent connection
• Configuration: Testable half kit (less tee, less pipe, less trim, with test devices)
• Test plug rating: 25 PSI - test up to four floors
• Flow rate: 8.25 GPM
• Certification: CCSA US UPC Certification
