FRZERO FR-PVC Offset Waste & Overflow Rough-In Kit (2550RI-K)

The OS&B FRZERO 2550RI-K is a 1-1/2" FR-PVC offset waste and overflow rough-in kit. It features a spin-on tie plate, an angle adapter (use optional) and a large strainer, and the kit comes with a tee, less 1-1/2" pipe. The fire-rated PVC kit will not support combustion in the presence of an ignition source.

Features

• Spin-on tie plate for a tool less installation
• Angle adapter included; use optional
• Thick foam overflow gasket with adhesive back
• Overflow head with aggressive threads for a quicker and easier installation
• Self clinging rubber waste gasket
• Polished stainless steel coarse thread strainer
• Kit comes with a tee, less 1-1/2" pipe

Specifications

• Material: FR-PVC
• Type: Rough-in (non testable)
• Flame and smoke: CAN/ULC S102.2: Flame Spread Rating 0, Smoke Developed Rating 40
• Standard: ASME A112.18.2/CSA-B125.2
• Certifications: CCSA US UPC Certification; QAI Certification
• cCSAus mark: Meets UPC & IPC Code; the product conforms to the requirements of the NPC, UPC, IPC, and IRC
