Cast Iron Island Tub Drain® Testable Rough-in for Freestanding Bath Tubs (ID357)

The OS&B Cast Iron Island Tub Drain® (ID357) is a two-piece cast iron testable rough-in drain for freestanding bath tubs. It is a freestanding tub rough-in that is installed before tile installation. It allows the freestanding tub location to be defined at rough-in and allows the tub to be installed over finished floor. The Island Tub Drain® lets you install a freestanding bath tub in minutes.

Features

• Built-in snap-off test cap allows for water/air/smoke testing (rated to 30psi)
• Asymmetrical deck flange makes installation in tight spaces easier
• 18 gauge epoxy-coated metal deck plate with holes to lock in thinset
• 2" IPT female thread connection
• 2 brass tailpieces (fine thread and flanged)
• ABS or PVC adapter kit attaches the ID357™ to ABS or PVC bath wastes
• Mortar/tile guard and Island Drain assembly
• Not for use with liquid applied or sheet membranes
• Must be installed in a dry area with no potential of water contact
• Patented: Canadian Patent 2,813,010 and US Patent 9,551,138

Specifications

• Material: Cast Iron
• Connection: 2" IPT female thread
• Test cap rating: 30psi
• Deck plate: 18 gauge epoxy coated metal
• Certification: CCSA US UPC Certification
• Code mark: cCSAus Meets UPC; conforms to the requirements of the NPC, UPC, IPC and IRC
