2-In-1 Integral Touchless Faucet/Soap Dispenser, Base Model

The sleek 2-In-1 Integral Touchless Faucet/Soap Dispenser from American Standard is an innovative solution for hygienic, hands-free hand-washing that helps to reduce the spread of germs with its contactless convenience. This unique integrated combination features two infrared sensors: one to dispense water and another to dispense a rich, foam soap. Clean, contemporary design is ideal for new projects and a smart, easy update for retrofit applications, from the industry’s most trusted name in bathroom fittings.

Features

• Flexible single post design can be installed on sinks with single-hole (CHO) or 4" centerset. Deck plate sold separately.
• Two separate infrared sensors
• To activate, place hand near sensor on side of spout to dispense soap; place hand under front of spout to dispense water
• Rectangular 1.2 gpm pressure-compensating, vandal-resistant aerator
• Brass spout and shank
• Below deck soap and air pump
• Adjustable foam volume (4 levels)
• Uses any brand of foam soap that meets viscosity requirements of 1-20 cps; no proprietary soaps needed
• Includes 1.8L soap bottle with quick release button
• Base model uses existing American Standard AC power kits, sold separately,Optional 4-inch deck plate, sold separately, for easy installation on sink with 4" centerset
• Base model uses the existing American Standard Plug-In or Hard-Wired AC power kits (sold separately)
• Stylish spout dispenses foam soap and water for a hygienic hand wash
• Touchless operation limits the spread of germs
• Uses universal bulk foam soap; no proprietary soaps needed
• Air infused foam soap generator with 4 adjustable foam volume settings
• Includes 1,800 ml soap bottle with quick disconnect
• Vandal-resistant brass spout with single-hole installation
• Vandal-resistant 1.2 gpm/4.5 Lpm rectangular aerator
• Optional deck plate for 4" (102 mm) centers available

Specifications

• ADA Compliant: Yes
• Barrier Free: Yes
• Brand: American Standard
• Cal Green: Yes
• Category: Commercial Fittings
• CEC Certified: Yes
• Color / Finish: Chrome
• Department of Energy Certified: Yes
• Collections: Selectronic
• WaterSense: Yes
• Fitting Material: Brass
• Spout Type: High Arc
• Touchless: Touchless
• Fixture or Fitting Material: Brass
• Gallons Per Minute (min-max): 1.2 GPM
• Hardware Included: Yes
• Height: 8-11/16
• Width: 1-9/16
• Residential or Commercial: Commercial
• Subcategory: Sensor Commercial Fittings
• Warranty: 5 Year Limited Warranty
• Water Efficient: Yes
