PVC OFFSET WASTE & OVERFLOW CLICKER® HALF KIT (5152QHK)

The OS&B PVC Offset Waste & Overflow Clicker® Half Kit (5152QHK) is a Schedule 40 PVC offset waste and overflow half kit with a Clicker® stopper. The half kit comes less tee, less 1-1/2" pipe. It features a SlideOn™ faceplate, a spin-on tie plate and an angle adapter, plus a large strainer with Clicker® stopper.

Features

• SlideOn™ faceplate
• Thick foam overflow gasket with adhesive back
• Spin-on tie plate for a tool-less installation
• Overflow head with an integrated 6 degree angle
• Overflow head with aggressive threads for a quicker and easier installation
• Angle adapter included; its use is optional
• Self-clinging rubber waste gasket
• Large coarse-thread strainer with Clicker® stopper

Specifications

• Material: PVC
• Length: Half Kit
• Size: 1-1/2"
• Kit: Less tee, less 1-1/2" pipe
• Standard: ASME A112.18.2/CSA-B125.2
• Code mark: cCSAus Meets UPC & IPC Code; conforms to the requirements of the NPC, UPC, IPC and IRC
• Available finishes: Brass Chrome Plated, Brushed Gold, Brushed Nickel, Chrome Plated, Luxe Bronze, Matte Black, Polished Nickel, Venetian Bronze, White
