Eclissi™ Single Handle Tall Lavatory Faucet Ec02d1iw

The ROHL Eclissi™ Single Handle Tall Lavatory Faucet EC02D1IW is a single-hole, deck-mount bathroom sink faucet with a column spout. It is made of brass and flows 1.2 GPM/4.5 LPM at 60 PSI (WaterSense and CEC compliant). The outer handle finish always matches the spout finish, and the inner accent can be chosen separately.

Features

• Flow rate of 1.2 GPM/4.5 LPM at 60 PSI, WaterSense and CEC compliant
• Meets ASME A112.18.1/CSA B125.1
• Outer handle finish and spout finish are always the same
• Inner accent finish options: Polished Chrome, Satin Nickel, Matte Black, Satin Gold
• 1 3/8” hole size with 1 37/64” max deck depth
• 24” supply lines with 9/16” female connections
• Drain assembly not included; a drain must be ordered to complete the faucet

Specifications

• Model: EC02D1IW
• Collection: Eclissi
• Installation: Single hole, deck mount
• Spout: Column spout
• Hole size: 1 3/8”
• Max deck depth: 1 37/64”
• Centre to centre reach: 7 33/64”
• Total length: 9 29/64”
• Total height: 12 23/64”
• Flow rate: 1.2 GPM/4.5 LPM at 60 PSI
• Standards: ASME A112.18.1/CSA B125.1; WaterSense and CEC compliant
• Material: Brass
• Style: Transitional
• Available finishes: Polished Chrome, Matte Black, Matte Black/Polished Chrome, Matte Black/Satin Gold, Matte Black/Satin Nickel, Polished Chrome/Matte Black, Polished Chrome/Satin Gold, Polished Chrome/Satin Nickel, Satin Gold, Satin Gold/Matte Black, Satin Gold/Polished Chrome, Satin Gold/Satin Nickel, Satin Nickel/Matte Black, Satin Nickel/Polished Chrome, Satin Nickel/Satin Gold, Satin Nickel
• Warranty (Polished Chrome, EC02D1IWAPC): Limited Lifetime Warranty
• Country of origin (Polished Chrome, EC02D1IWAPC): Italy
